- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Particularly large weighing plate
- Very fast display: steady weight values within 2 s
- Simple and convenient 2-key operation
- Warehouse logistics
- Checkweighing
- Workshops
- Gastronomy
- Order picking
Weighing range (Max): 50 kg
Readability (g): 0,02 kg
Reproducibility: 0,02 kg
linearity: ± 0,08 kg
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-133H
Material housing: cast aluminium
Dimension completely mounted (W×D×H): 300×190×850 mm
Dimension completely mounted (Width): 300 mm
Dimension completely mounted (Depth): 190 mm
Dimension completely mounted (Height): 850 mm
Display type: LED segments
Display digit height: 30 mm
Units: kg
Supplied power supply: Accu & Power supply
Battery / accumulator type: Pb
Rechargeable battery charging time: 14 h
Rechargeable battery operating time - backlight on: 50 h
Rechargeable battery operating time - backlight off: 50 h
Auto-off interval(s) in battery mode/rechargeable battery mode: off,5 min,10 min,30 min,20 min
Battery: 1×12 V, Type 23 A
Battery operating time: 50 h
Input voltage power supply / power [Max]: 220 V - 240 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Plug-in power supply type: Power adapter
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 0 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 44 kg
Net weight: 34 kg
UN number (hazardous goods): 2800
UN number (hazardous goods): Lead acid (UN 2800, Packaging Instruction #2, Not Restricted as per Special Provision A67)
Airworthy: yes, with dispatch instructions (in accordance with IATA classification)
Shipping method: Freight
Dimensions packaging (W×D×H): 800×600×600 mm
Dimensions packaging Width: 800 mm
Dimensions packaging Depth: 600 mm
Dimensions packaging Height: 600 mm
Total packaging weight: 9,1 kg
Packaging component carton/cardboard: 4550 g
Packaging component Styrofoam: 4550 g
Tolerance (% of [Max]): 0,2%
Pictograms Standard: External adjustment; Rechargeable battery; Universal plug-in power supply; Weighing principle Strain gauges; Delivery Truck 2 days
Pictograms Option: Accredited calibration (DKD)
Accessories: PFB-A03; PFB-A04; PFB-A02; HFM-A01; YKA-11
