- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Particularly large weighing plate
- Very fast display: steady weight values within 2 s
- Simple and convenient 2-key operation
- Warehouse logistics
- Checkweighing
- Workshops
- Gastronomy
- Order picking
Weighing range (Max): 10 kg
Readability (g): 0,005 kg
Reproducibility: 0,005 kg
linearity: ± 0,02 kg
Ambient temperature [Min] (°C): -35 °C
Ambient temperature [Max] (°C): 65 °C
Gross weight: 0,25 kg
Net weight: 0,20 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 160×95×45 mm
Dimensions packaging Width: 160 mm
Dimensions packaging Depth: 95 mm
Dimensions packaging Height: 45 mm
Total packaging weight: 40 g
Packaging component carton/cardboard: 40 g
Load cell OIML class: C3
Load cell - Resolution (verifiable): 3000 e
Load cell - Y-value: 10000
Directions of force: compression
Maximum platform size: 250×350 mm
Cable length: 0,4 m
Load cell connection: 4-wire
Pictograms Standard: Protection against dust and water splashes IP65; Conformity assessment; Package shipment 1 day
Pictograms Option: Factory calibration (ISO); Accredited calibration (DKD)
Accessories: YKV-01; CJ P2; YKV-02; CJ P4PG; CJ P4; CE WT1-Y1; CE WT3-Y1; CE WT1-Y2; CE WT1-Y4; CJ X468; CJ X467
