- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
- Programmable using numerical key pad:
- required reference quantity
- known reference weight - Three displays for weight display, reference weight, total pieces
- Weighing with tolerance range (checkweighing): a visual and audible signal helps with portioning, dispensing or grading
- Fill-to-target function: Programmable target quantity or target weight e.g. for checkweighing. A signal will be displayed when the target value is reached
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- Second balance interface to construct a high-resolution counting system, standard, e.g. with weighing bridges of KERN KFP V20
- Protective working cover included with delivery
- Warehouse logistics
- Industrial applications
- Production monitoring
- quality control
- Counting applications
- Order picking and inventory
Weighing range (Max): 30 kg
Readability (g): 0,0005 kg
Reproducibility: 0,0005 kg
linearity: ± 0,001 kg
Weighing system: Strain gauge
Stabilization time: 3 s
Article number for DAkkS calibration: 963-129
Material housing: plastic
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 550×550×58 mm
Dimension weighing platform (Width): 550 mm
Dimension weighing platform (Depth): 550 mm
Dimension weighing platform (Height): 58 mm
Dimensions weighing surface (W×D): 550×550 mm
Dimension weighing surface (Width): 550 mm
Dimension weighing surface (Depth): 550 mm
Display type: LCD
Display digit height: 25 mm
Units: kg; lb; PCS
Supplied power supply: Power supply unit
Battery / accumulator type: Alkali(-Manganese)
Auto-off interval(s) in battery mode/rechargeable battery mode: off,1 min - 99 min
Battery: 4×1.5 V AA
Battery operating time: 60 h
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,AUS,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,UK,US,CH
Plug-in power supply type: Power adapter
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 35 °C
Gross weight: 13 kg
Net weight: 13 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 665×600×90 mm
Dimensions packaging Width: 665 mm
Dimensions packaging Depth: 600 mm
Dimensions packaging Height: 90 mm
Total packaging weight: 680 g
Packaging component carton/cardboard: 735 g
Packaging component plastic: 12 g
Pictograms Standard: External adjustment; Piece counting function; Units switchable; Hold function (average value); Prepared for battery operation; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: EOB-A02B; EOB-A04BS05; EOC-A04; YKA-16; EOB-A04B
