- Scope of delivery: 2 pieces
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for conformity assessment: 965-229
Article number for DAkkS calibration: 963-129
Material housing: plastic
Dimension completely mounted (W×D×H): 810×500×820 mm
Dimension completely mounted (Width): 810 mm
Dimension completely mounted (Depth): 500 mm
Dimension completely mounted (Height): 820 mm
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 650×500×139 mm
Dimension weighing platform (Width): 650 mm
Dimension weighing platform (Depth): 500 mm
Dimension weighing platform (Height): 139 mm
Dimensions weighing surface (W×D): 650×500 mm
Dimension weighing surface (Width): 650 mm
Dimension weighing surface (Depth): 500 mm
Display type: LCD
Display digit height: 52 mm
Units: kg
Supplied power supply: Power supply unit
Battery / accumulator type: Pb
Rechargeable battery optional: Rchrg. battery optional
Rechargeable battery charging time: 12 h
Rechargeable battery operating time - backlight on: 8 h
Rechargeable battery operating time - backlight off: 35 h
Auto-off interval(s) in battery mode/rechargeable battery mode: off,5 min,15 min
Battery: no battery
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard,Bluetooth BTC (v2.0) (optional, factory),analogue (0 - 10 V) (optional, factory),analogue (4 - 20 mA) (optional, factory)
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 24 kg
Net weight: 20 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 670×1050×245 mm
Dimensions packaging Width: 670 mm
Dimensions packaging Depth: 1050 mm
Dimensions packaging Height: 245 mm
Total packaging weight: 4 kg
Packaging component carton/cardboard: 2 kg
Packaging component Styrofoam: 2 kg
Load cell connection: 6-wire
Pictograms Standard: External adjustment; Data interface RS-232; Interface command set KERN Communication Protocol (KCP); Piece counting function; Sum function; Measuring with tolerance range (checkweighing function); Hold function (average value); Load Cell: Protection against dust and water splashes IP65; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Pictograms Factory: Data Interface Bluetooth; Analogue interface; Rechargeable battery; Conformity assessment
Accessories: BFS-A07; IFB-A01; IFB-A02; KFB-A02; CFS-A03; CFS-A04; YKN-01; YKI-02; KFB-A02S05; YRO-03; KFB-A04; KFB-A03; KFB-A05; YKD-A02; CFS-A01; YKC-01; KFB-A01; PFB-A03; PFB-A04; YKA-11
