- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Display device: plastic
- Display device flexible positioning e. g. free-standing or screwed to the wall
- Weighing plate stainless steel, painted steel base
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- With the recipe function you can weigh the different ingredients of a mixture. As a check, you can also call up the total weight of all the ingredients
- Freely programmable weighing unit, e.g. display direct in special units such as length of thread g/m, paper weight g/m², or similar
- Protective working cover included with delivery
- Warehouse logistics
- Dispatch
- Industrial applications
Weighing range (Max): 60 kg; 150 kg
Readability (g): 0,02 kg; 0,05 kg
Reproducibility: 0,02 kg; 0,05 kg
linearity: ± 0,06 kg; 0,15 kg
Weighing system: Force compensation
Stabilization time: 2 s
Article number for DAkkS calibration: 963-127
Material housing: ABS plastic
Dimension completely mounted (W×D×H): 213×322×101 mm
Dimension completely mounted (Width): 213 mm
Dimension completely mounted (Depth): 322 mm
Dimension completely mounted (Height): 101 mm
Material weighing plate: stainless steel
Dimensions weighing surface (W×D): 185×185 mm
Dimension weighing surface (Width): 185 mm
Dimension weighing surface (Depth): 185 mm
Display type: LCD
Display digit height: 20 mm
Units: kg; g; mg; gn; dwt; tl (Tw); ozt; ct; lb; N; oz; ffa
Supplied power supply: Power supply unit
Input voltage power supply / power [Max]: 100 V - 240 V AC, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard,USB-Device
Humity of environment [Min]: 15 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 15 °C
Ambient temperature [Max] (°C): 25 °C
Gross weight: 6 kg
Net weight: 3,6 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 370×470×340 mm
Dimensions packaging Width: 370 mm
Dimensions packaging Depth: 470 mm
Dimensions packaging Height: 340 mm
Total packaging weight: 2 kg
Packaging component carton/cardboard: 1 kg
Packaging component Styrofoam: 1 kg
Packaging component glass: 0 g
Packaging component wood: 0 g
Pictograms Standard: Internal adjustment; Data interface RS-232; Data Interface USB; Interface command set KERN Communication Protocol (KCP); GLP/ISO Protocol; Value & time; Piece counting function; Net-Total function; Density determination function; Percentage determination function; Units switchable; Measuring with tolerance range (checkweighing function); Hold function (average value); Suspended weighing; Universal plug-in power supply; Weighing principle: Electromagnetic force compensation; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: 316-12; YKN-01; YKG-01; YKH-01; 572-926; 315-312-407; YPS-03; YPS-04; YPS-05; YKC-01; YKI-10; YKI-11; YKI-12; YKT-01; YKA-13
