- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Display device: plastic
- Display device flexible positioning e. g. free-standing or screwed to the wall
- Weighing plate stainless steel, painted steel base
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- With the recipe function you can weigh the different ingredients of a mixture. As a check, you can also call up the total weight of all the ingredients
- Freely programmable weighing unit, e.g. display direct in special units such as length of thread g/m, paper weight g/m², or similar
- Protective working cover included with delivery
- Warehouse logistics
- Dispatch
- Industrial applications
Weighing range (Max): 6000 g; 15000 g
Readability (g): 2 g; 5 g
Reproducibility: 2 g; 5 g
linearity: ± 6 g; 15 g
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for conformity assessment: 965-228
Article number for DAkkS calibration: 963-128
Material housing: stainless steel, plastic
Dimension housing (W×D×H): 288×233×102 mm
Dimension housing (Width): 288 mm
Dimension housing (Depth): 233 mm
Dimension housing (Height): 102 mm
Dimension completely mounted (W×D×H): 288×233×102 mm
Dimension completely mounted (Width): 288 mm
Dimension completely mounted (Depth): 233 mm
Dimension completely mounted (Height): 102 mm
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 230×190×20 mm
Dimension weighing platform (Width): 230 mm
Dimension weighing platform (Depth): 190 mm
Dimension weighing platform (Height): 20 mm
Dimensions weighing surface (W×D): 190×230 mm
Dimension weighing surface (Width): 190 mm
Dimension weighing surface (Depth): 230 mm
Display type: LCD
Display digit height: 25 mm
Units: kg; g; PCS
Supplied power supply: Accu & Power supply
Battery / accumulator type: Li-Ion
Rechargeable battery charging time: 4 h
Rechargeable battery operating time - backlight on: 400 h
Rechargeable battery operating time - backlight off: 500 h
Auto-off interval(s) in battery mode/rechargeable battery mode: selectable
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO
Plug-in power supply / adapter for countries - option: EURO
Plug-in power supply type: USB including power supply
Humity of environment [Min]: 5 %
Humity of environment [Max]: 85 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 3,6 kg
Net weight: 2,2 kg
UN number (hazardous goods): 3481
UN number (hazardous goods): automatic definition not possible
Airworthy: cannot be determined automatically
Shipping method: Parcel service
Dimensions packaging (W×D×H): 340×295×165 mm
Dimensions packaging Width: 340 mm
Dimensions packaging Depth: 295 mm
Dimensions packaging Height: 165 mm
Total packaging weight: 1,3 kg
Packaging component Paper: 100 g
Packaging component carton/cardboard: 401 g
Packaging component plastic: 99 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Load cell connection: 4-wire
Pictograms Standard: External adjustment; Piece counting function; Units switchable; Measuring with tolerance range (checkweighing function); Protection against dust and water splashes IP68; Protection against dust and water splashes IP69K; Rechargeable battery; Plug-in power supply 230V/50 Hz; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Pictograms Factory: Conformity assessment
