- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Display device: plastic
- Display device flexible positioning e. g. free-standing or screwed to the wall
- Weighing plate stainless steel, painted steel base
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- With the recipe function you can weigh the different ingredients of a mixture. As a check, you can also call up the total weight of all the ingredients
- Freely programmable weighing unit, e.g. display direct in special units such as length of thread g/m, paper weight g/m², or similar
- Protective working cover included with delivery
- Warehouse logistics
- Dispatch
- Industrial applications
Weighing range (Max): 24 kg
Readability (g): 0,002 kg
Reproducibility: 0,002 kg
linearity: ± 0,006 kg
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-128H
Material housing: plastic
Dimension housing (W×D×H): 72×25×105 mm
Dimension housing (Width): 72 mm
Dimension housing (Depth): 25 mm
Dimension housing (Height): 105 mm
Dimension completely mounted (W×D×H): 72×25×188 mm
Dimension completely mounted (Width): 72 mm
Dimension completely mounted (Depth): 25 mm
Dimension completely mounted (Height): 188 mm
Display type: LCD
Display digit height: 12 mm
Units: kg; lb; N
Supplied power supply: Battery
Battery / accumulator type: Alkali(-Manganese)
Rechargeable battery operating time - backlight off: 100 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min
Battery: 2×1.5 V AAA
Battery operating time: 100 h
Humity of environment [Max]: 90 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 35 °C
Gross weight: 0,45 kg
Net weight: 0,20 kg
UN number (hazardous goods): Drycell (Alkalines, nickel-cadmium, zinc-carbon, Packing instruction #1, Not Restricted as per Special Provision A123)
Airworthy: yes, with dispatch instructions (in accordance with IATA classification)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 225×150×70 mm
Dimensions packaging Width: 225 mm
Dimensions packaging Depth: 150 mm
Dimensions packaging Height: 70 mm
Total packaging weight: 239 g
Packaging component Paper: 17 g
Packaging component carton/cardboard: 690 g
Packaging component plastic: 1 g
Packaging component Styrofoam: 77 g
Packaging component wood: 16 g
Tolerance (% of [Max]): 0,5%
Internal measuring frequency: 5 Hz
Load cell connection: 4-wire
Pictograms Standard: External adjustment; Units switchable; Hold function (average value); Prepared for battery operation; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: CH-A01N; 346-77
