Quantity
|
Cost
|
||
|
|
|||
|
|
|||
Individual plug-in phase-contrast unit with ∞ PH plan objective 10×, for 10×
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for conformity assessment: 965-232
Article number for DAkkS calibration: 963-132
Material weighing plate: steel, powder-coated
Dimension weighing platform (W×D×H): 1500×1500×108 mm
Dimension weighing platform (Width): 1500 mm
Dimension weighing platform (Depth): 1500 mm
Dimension weighing platform (Height): 108 mm
Dimensions weighing surface (W×D): 1500×1500 mm
Dimension weighing surface (Width): 1500 mm
Dimension weighing surface (Depth): 1500 mm
Display type: LCD
Display digit height: 25 mm
Supplied power supply: Power supply & battery function (battery not included)
Plug-in power supply type: Power adapter
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 175 kg
Net weight: 135 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Freight
Dimensions packaging (W×D×H): 1580×1580×250 mm
Dimensions packaging Width: 1580 mm
Dimensions packaging Depth: 1580 mm
Dimensions packaging Height: 250 mm
Total packaging weight: 42 kg
Packaging component carton/cardboard: 840 g
Packaging component wood: 41160 g
Cable length: 5 m
Load cell connection: 4-wire
Pictograms Standard: Load Cell: Protection against dust and water splashes IP67; Delivery Truck 2 days
Pictograms Factory: Conformity assessment
Accessories: BIC-A03; BIC-A06; BIC-A07; YKV-01; YKV-02
Technical Data Sheet (PDF)
