- Simple and convenient 2-key operation
- Tare function facilitates formulation work
- Particularly flat design
- Ready for use: Batteries included
- Hook for underfloor weighing standard
- Note: With the optional auxiliary set for density determination KERN YDB-04 also well suited for school and teaching operation
As School Balance
- Teaching and training
- educational institutions
- Cosmetics industry
- Quality assurance
As Small Pet Scale
- veterinary practices
- Weighing small animals
- Breeding small animals
Weighing range (Max): 500 g
Readability (g): 0,1 g
Reproducibility: 0,1 g
linearity: ± 0,2 g
Weighing system: Strain gauge
Article number for DAkkS calibration: 963-129
Material housing: steel, lacquered
Dimension completely mounted (W×D×H): 315×450×1000 mm
Dimension completely mounted (Width): 315 mm
Dimension completely mounted (Depth): 450 mm
Dimension completely mounted (Height): 1000 mm
Material weighing plate: steel, lacquered
Dimension weighing platform (W×D×H): 315×300×55 mm
Dimension weighing platform (Width): 315 mm
Dimension weighing platform (Depth): 300 mm
Dimension weighing platform (Height): 55 mm
Display type: LCD
Display digit height: 25 mm
Units: kg
Supplied power supply: Power supply unit
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,off,4 min,5 min,2 min
Battery: 6×1.5 V AA
Battery operating time: 170 h
Input voltage power supply / power [Max]: 220 V - 240 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,CH
Plug-in power supply / adapter for countries - option: EURO,UK,CH
Plug-in power supply type: Power adapter
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 35 °C
Gross weight: 10 kg
Net weight: 7 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 1175×410×330 mm
Dimensions packaging Width: 1175 mm
Dimensions packaging Depth: 410 mm
Dimensions packaging Height: 330 mm
Total packaging weight: 3,6 kg
Packaging component carton/cardboard: 720 g
Packaging component plastic: 1,8 kg
Packaging component Styrofoam: 2880 g
Pictograms Standard: External adjustment; Hold function; Prepared for battery operation; Universal plug-in power supply; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: MSF 200; MPB-A02; YKA-29
