- Wide range of functions including statistics, recipe and totalling functions Weighing with tolerance range (checkweighing): a visual and audible signal helps with portioning, dispensing or grading
- Standardised, convenient KERN concept of operation: All primary functions have their own key on the keypad
- Automatic internal adjustment, time-controlled every 2 h, guarantees high degree of accuracy and makes the balance independent of its location
- Capacity display: A bargraph display lights up to show how much of the weighing range is still available
- USB data interface for transferring weighing data to the PC, printer etc.
- Small draught shield as standard, removable, Weighing space W×D×H 134×128×80 mm
- Protective working cover included with delivery
- Jewellery and gold trade
- quality control
- Laboratory applications
- Dental laboratories
- Plastics technology
Weighing range (Max): 300 g
Readability (g): 0,001 g
Reproducibility: 0,003 g
linearity: ± 0,005 g
Article number for DAkkS calibration (tensile force): 963-161
Article number for DAkkS calibration (compressive force): 963-261
Article number for DAkkS calibration (tensile force/compressive force): 963-361
Article number for factory calibration (tensile force): 961-161
Article number for factory calibration (compressive force): 961-261
Article number for factory calibration (tensile force/compressive force): 961-361
Dimension completely mounted (W×D×H): 230×66×36 mm
Dimension completely mounted (Width): 230 mm
Dimension completely mounted (Depth): 66 mm
Dimension completely mounted (Height): 36 mm
Display type: LCD
Display digit height: 10 mm
Supplied power supply: Accu & Power supply
Battery / accumulator type: NiMH
Rechargeable battery charging time: 4 h
Rechargeable battery operating time - backlight on: 10 h
Rechargeable battery operating time - backlight off: 12 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 1 - 60 min
Input voltage power supply / power [Max]: 100 - 240 V
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard
Ambient temperature [Min] (°C): 10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 11 kg
Net weight: 10 kg
UN number (hazardous goods): 3496
UN number (hazardous goods): NiMH (7 - not restricted as per A199)
Airworthy: yes, but rework required before delivery (special item)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 570×275×300 mm
Dimensions packaging Width: 570 mm
Dimensions packaging Depth: 275 mm
Dimensions packaging Height: 300 mm
Total packaging weight: 1 kg
Measuring range force [Max] (N): 500 N
Readability force [d] (N): 0,1 N
Overload protection (% of [Max]): 150%
Tolerance (% of [Max]): 0,5%
Generated force [Max]: 500 N
Type of drive: manual crank handle
Measuring head measuring frequency: 2 kHz
Directions of force: tension,compression
Pictograms Standard: Peak hold function; Push and Pull; Length measurement; Device-internal Memory; Data interface RS-232; Data Interface USB; Statistics function; Measuring with tolerance range (checkweighing function); ZERO function; Rechargeable battery; Plug-in power supply 230V/50 Hz; Package shipment 1 day
Pictograms Option: PC software; Factory calibration (ISO); Accredited calibration (DKD)
Accessories: YKA-01; AC 01; AC 02; AC 03; AC 12; AC 14; AC 09; AC 22; AC 18; AFH 04; AC 43; AD 9021; AD 9030; AD 9031; AD 9032; AD 9033; AD 9050; AD 9120; AD 9205; AD 9206; AD 9305; AD 9315; AC 01R; AC 02R; AC 03R; AC 09R; AC 11R; AC 12R; AC 14R; AC 18R; AC 22R; AFM 01; AFM 02; AFM 03; AFM 05; AFM 06; AFM 07; AFM 08; AFM 12; AFM 13; AFM 14; AFM 15; AFM 22; AE 01; AE 02; AE 03; AE 04; AE 05; AE 06; AE 07; AC 45; AC 46; AC 47; AE 08R; AE 08; FH-A04; AE 500; AFM 20; YKA-02; FS-E07
