Quantity
|
Cost
|
||
|
|
|||
|
|
|||
- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
- Programmable using numerical key pad:
- required reference quantity
- known reference weight - Three displays for weight display (verifiable), reference weight, total pieces
- Fill-to-target function: Target count or target weight can be programmed. When the target weight is reached there is an audible and visual signal
- 10 memories for reference weights
- Counting results memory: adds up all individual piece counts, result is shown in total weight and total pieces
- Integrated ESD protection, which makes it ideal for weighing small plastic parts
- Energy management: Backlight turns off after 5 sec
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- Two balances in one: Changes from counting mode to weighing mode at the touch of a key
- Protective working cover included with delivery
- Warehouse logistics
- Packaging industry
- Retail
- Counting applications
- Order picking and inventory
Weighing range (Max): 30000 g
Readability (g): 2 g
Reproducibility: 2 g
linearity: ± 4 g
Weighing system: Tuning fork
Stabilization time: 3 s
Article number for DAkkS calibration: 963-127
Material housing: plastic
Dimension housing (W×D×H): 196×293×89 mm
Dimension housing (Width): 196 mm
Dimension housing (Depth): 293 mm
Dimension housing (Height): 89 mm
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 190×190×89 mm
Dimension weighing platform (Width): 190 mm
Dimension weighing platform (Depth): 190 mm
Dimension weighing platform (Height): 89 mm
Dimensions weighing surface (W×D): 190×190 mm
Dimension weighing surface (Width): 190 mm
Dimension weighing surface (Depth): 190 mm
Display type: LCD
Display digit height: 16,5 mm
Units: g; dwt; tl (Tw); tl (HK); ozt; tl (Singap, Malays); ct; mo; lb; oz; tol
Supplied power supply: Power supply unit
Input voltage power supply / power [Max]: 220 V - 240 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,AUS,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 3,8 kg
Net weight: 2,8 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 325×410×205 mm
Dimensions packaging Width: 325 mm
Dimensions packaging Depth: 410 mm
Dimensions packaging Height: 205 mm
Total packaging weight: 1 kg
Packaging component Paper: 165 g
Packaging component carton/cardboard: 905 g
Packaging component plastic: 30 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 100 g
Pictograms Standard: External adjustment; Data interface RS-232; GLP/ISO Protocol; Value & time; Piece counting function; Percentage determination function; Units switchable; Measuring with tolerance range (checkweighing function); Universal plug-in power supply; Weighing principle: Tuning fork; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: YKN-01; YKI-02; PNJ-A01S05; YKG-01; YKH-01; MLB-A05; YPS-03; YPS-04; YPS-05; REWN-2001_2.0; YKC-01; YKI-10; YKI-11; YKI-12; YKT-01; YKA-18; PNJ-A01.
Technical Data Sheet (PDF)
