- High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
- Display device: plastic
- Display device flexible positioning e. g. free-standing or screwed to the wall
- Weighing plate stainless steel, painted steel base
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- With the recipe function you can weigh the different ingredients of a mixture. As a check, you can also call up the total weight of all the ingredients
- Freely programmable weighing unit, e.g. display direct in special units such as length of thread g/m, paper weight g/m², or similar
- Protective working cover included with delivery
- Warehouse logistics
- Dispatch
- Industrial applications
Weighing range (Max): 150 kg; 300 kg
Readability (g): 0,05 kg; 0,1 kg
Reproducibility: 0,05 kg; 0,1 kg
linearity: ± 0,15 kg; 0,3 kg
Weighing system: Strain gauge
Stabilization time: 2,5 s
Article number for DAkkS calibration: 963-129
Dimension housing (W×D×H): 315×305×75 mm
Dimension housing (Width): 315 mm
Dimension housing (Depth): 305 mm
Dimension housing (Height): 75 mm
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 318×308×75 mm
Dimension weighing platform (Width): 318 mm
Dimension weighing platform (Depth): 308 mm
Dimension weighing platform (Height): 75 mm
Dimensions weighing surface (W×D): 315×305 mm
Dimension weighing surface (Width): 315 mm
Dimension weighing surface (Depth): 305 mm
Display type: LCD
Display digit height: 25 mm
Units: kg; dwt; tl (Tw); tl (HK); ozt; mo; lb; oz; ffa; tol
Supplied power supply: Power supply unit
Battery / accumulator type: NiMH
Rechargeable battery optional: Rchrg. battery optional
Rechargeable battery charging time: 10 h
Rechargeable battery operating time - backlight on: 15 h
Rechargeable battery operating time - backlight off: 30 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,off
Battery: 9 V block
Battery operating time: 12 h
Input voltage power supply / power [Max]: 220 V - 240 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 35 °C
Gross weight: 6 kg
Net weight: 5,0 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 515×395×140 mm
Dimensions packaging Width: 515 mm
Dimensions packaging Depth: 395 mm
Dimensions packaging Height: 140 mm
Total packaging weight: 800 g
Packaging component carton/cardboard: 1738 g
Packaging component plastic: 11 g
Packaging component Styrofoam: 480 g
Packaging component foam: 127 g
Pictograms Standard: External adjustment; Data interface RS-232; Piece counting function; Sum function; Percentage determination function; Units switchable; Hold function (average value); Prepared for battery operation; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Rechargeable battery; Accredited calibration (DKD)
Accessories: DE-A10; DE-A13; YKN-01; YKI-02; AFH 13; YKG-01; 572-926; YKC-01; YKI-10; YKI-11; YKI-12; YKT-01; NDE-A02; DE-A12; YKA-06
