Power supply adapter set
Weighing system: Strain gauge
Stabilization time: 3 s
Article number for conformity assessment: 965-129
Article number for DAkkS calibration: 963-129
Material housing: steel, lacquered
Dimension completely mounted (W×D×H): 500×455×120 mm
Dimension completely mounted (Width): 500 mm
Dimension completely mounted (Depth): 455 mm
Dimension completely mounted (Height): 120 mm
Material weighing plate: plastic
Dimension weighing platform (W×D×H): 500×455×120 mm
Dimension weighing platform (Width): 500 mm
Dimension weighing platform (Depth): 455 mm
Dimension weighing platform (Height): 120 mm
Display type: LCD
Display digit height: 25 mm
Units: kg
Supplied power supply: Power supply & battery function (battery not included)
Battery / accumulator type: Alkali(-Manganese)
Rechargeable battery optional: Rchrg. battery optional - intern
Rechargeable battery charging time: 12 h
Rechargeable battery operating time - backlight on: 20 h
Rechargeable battery operating time - backlight off: 40 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,5 min,30 min,15 min
Battery: 6×1.5 V AA
Battery operating time: 20 h
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,CH
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 (optional, factory)
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 15 kg
Net weight: 11 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 940×555×215 mm
Dimensions packaging Width: 940 mm
Dimensions packaging Depth: 555 mm
Dimensions packaging Height: 215 mm
Total packaging weight: 3,9 kg
Packaging component carton/cardboard: 200 g
Packaging component plastic: 500 g
Packaging component Styrofoam: 800 g
Pictograms Standard: Hold function; Prepared for battery operation; Universal plug-in power supply; Package shipment 1 day
Pictograms Option: Rechargeable battery; Accredited calibration (DKD)
Pictograms Factory: Data interface RS-232; Conformity assessment
Accessories: MBC-A06; MYC-01; YKI-02; MPC-A01; MBC-A06S05; AFH 13; YKG-01; YKH-01; CFS-A01; YKC-01; YKT-01; MBC-A08; MBC-A04-01; MBC-A04-02; YKA-43; YKA-44; MBC-A08-2024e
Technical Data Sheet (PDF)
