Individual weight, OIML Class F1, 10 kg, Eco Shape, stainless steel polished
Article number for DAkkS calibration (tensile force): 963-162
Article number for DAkkS calibration (compressive force): 963-262
Article number for DAkkS calibration (tensile force/compressive force): 963-362
Article number for factory calibration: 961-162
Article number for factory calibration (tensile force): 961-162
Article number for factory calibration (compressive force): 961-262
Article number for factory calibration (tensile force/compressive force): 961-362
Material housing: metal
Dimension housing (W×D×H): 145×73×34 mm
Dimension housing (Width): 145 mm
Dimension housing (Depth): 73 mm
Dimension housing (Height): 34 mm
Dimension completely mounted (W×D×H): 145×73×34 mm
Dimension completely mounted (Width): 145 mm
Dimension completely mounted (Depth): 73 mm
Dimension completely mounted (Height): 34 mm
Load support (tensile force): Hook
Display type: LCD
Display digit height: 10 mm
Supplied power supply: Accu & Power supply
Battery / accumulator type: NiMH
Rechargeable battery charging time: 4 h
Rechargeable battery operating time - backlight on: 20 h
Rechargeable battery operating time - backlight off: 20 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 1 - 60 min
Input voltage power supply / power [Max]: 100 V - 240 V
Plug-in power supply / adapter for countries - included with the delivery: EURO,CH
Plug-in power supply / adapter for countries - option: UK,US
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard,USB-Device
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 1,4 kg
Net weight: 0,95 kg
UN number (hazardous goods): 3496
UN number (hazardous goods): Ni-MH (UN 3496, Packing Instruction #0, Not Restricted as per Special Provision A199)
Airworthy: yes, but rework required before delivery (special item)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 337×160×110 mm
Dimensions packaging Width: 337 mm
Dimensions packaging Depth: 160 mm
Dimensions packaging Height: 110 mm
Total packaging weight: 275 g
Packaging component carton/cardboard: 230 g
Packaging component Styrofoam: 137,5 g
Measuring range force [Max] (N): 1 kN
Readability force [d] (N): 1 N
Overload protection (% of [Max]): 150%
Tolerance (% of [Max]): 0,3%
Measuring head measuring frequency: 1000 Hz
Directions of force: tension,compression
Pictograms Standard: Peak hold function; Push and Pull; Device-internal Memory; Data interface RS-232; Data Interface USB; Units switchable; Measuring with tolerance range (checkweighing function); ZERO function; Rechargeable battery; Plug-in power supply 230V/50 Hz; Package shipment 1 day
Pictograms Option: PC software; Factory calibration (ISO); Accredited calibration (DKD)
Accessories: YKA-01; AC 02; AC 03; AC 12; AC 09; AC 18; AFK 02; AC 43; AD 9021; AD 9030; AD 9031; AD 9032; AD 9033; AD 9050; AD 9090; AD 9120; AD 9205; AD 9206; AD 9250; AD 9305; AD 9310; AD 9315; AC 02R; AC 03R; AC 09R; AC 11R; AC 12R; AC 18R; FC-A01; AD 9302; AFM 05; AFM 06; AFM 07; AFM 12; AFM 15; AC 45; AC 46; AC 47; AE 08R; AE 08; YKA-02
