- Suitable for individual weights KERN 337, 347, 357, 367
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-128
Material housing: plastic
Dimension housing (W×D×H): 370×360×100 mm
Dimension housing (Width): 370 mm
Dimension housing (Depth): 360 mm
Dimension housing (Height): 100 mm
Dimension completely mounted (W×D×H): 370×360×125 mm
Dimension completely mounted (Width): 370 mm
Dimension completely mounted (Depth): 360 mm
Dimension completely mounted (Height): 125 mm
Material weighing plate: stainless steel
Dimensions weighing surface (W×D): 370×240 mm
Dimension weighing surface (Width): 370 mm
Dimension weighing surface (Depth): 240 mm
Display type: LCD
Display digit height: 20 mm
Units: kg; lb
Supplied power supply: Power supply unit
Battery / accumulator type: Pb
Rechargeable battery optional: Rchrg. battery optional
Rechargeable battery charging time: 14 h
Rechargeable battery operating time - backlight on: 40 h
Rechargeable battery operating time - backlight off: 70 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,off,5 min,30 min,15 min
Input voltage power supply / power [Max]: 220 V - 240 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Interfaces: RS-232 standard,Interface for a secondary balance
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 0 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 6 kg
Net weight: 4,4 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 470×440×205 mm
Dimensions packaging Width: 470 mm
Dimensions packaging Depth: 440 mm
Dimensions packaging Height: 205 mm
Total packaging weight: 1,5 kg
Packaging component carton/cardboard: 537 g
Packaging component Styrofoam: 179 g
Pictograms Standard: External adjustment; Device-internal Memory; Data interface RS-232; Interface command set KERN Communication Protocol (KCP); Piece counting function; Sum function; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Rechargeable battery; Accredited calibration (DKD)
Accessories: RFS-A02; CFS-A03; CFS-A04; 337-16; YKN-01; YKI-02; AFH 13; YKG-01; CFS-A01; YKC-01; YKI-10; YKI-11; YKI-12; YKT-01; PFB-A03; PFB-A04; GAB-A04; PFB-A02; YKA-11
