- Suitable for individual weights KERN 337, 347, 357, 367
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for conformity assessment: 965-228
Article number for DAkkS calibration: 963-128
Material housing: stainless steel, plastic
Dimension housing (W×D×H): 240×280×120 mm
Dimension housing (Width): 240 mm
Dimension housing (Depth): 280 mm
Dimension housing (Height): 120 mm
Dimension completely mounted (W×D×H): 240×280×120 mm
Dimension completely mounted (Width): 240 mm
Dimension completely mounted (Depth): 280 mm
Dimension completely mounted (Height): 120 mm
Material weighing plate: stainless steel
Dimensions weighing surface (W×D): 236×195 mm
Dimension weighing surface (Width): 236 mm
Dimension weighing surface (Depth): 195 mm
Display type: LCD
Display digit height: 25 mm
Units: kg; g
Supplied power supply: Battery
Battery / accumulator type: Alkali(-Manganese)
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,6 min,8 min,off,4 min,5 min,2 min,1 min,7 min,9 min
Battery: 4×1.5 V Size D
Battery operating time: 500 h
Battery operating time - backlight on: 200 h
Battery operating time - backlight off: 400 h
Humity of environment [Min]: 25 %
Humity of environment [Max]: 95 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 4,4 kg
Net weight: 3,0 kg
UN number (hazardous goods): 3496
UN number (hazardous goods): Drycell (UN number Alkaline: none, NiMH: 3496 - Packing instruction #1)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 325×365×225 mm
Dimensions packaging Width: 325 mm
Dimensions packaging Depth: 365 mm
Dimensions packaging Height: 225 mm
Total packaging weight: 1314 g
Packaging component Paper: 100 g
Packaging component carton/cardboard: 657 g
Packaging component plastic: 657 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Pictograms Standard: External adjustment; Piece counting function; Units switchable; Measuring with tolerance range (checkweighing function); Protection against dust and water splashes IP68; Prepared for battery operation; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Pictograms Factory: Conformity assessment
Accessories: RFS-A02
Technical Data Sheet (PDF)
