Quantity
|
Cost
|
||
|
|
|||
|
|
|||
- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Tough industry standard suitable for use in harsh industrial applications
- Ergonomic display device with large keypad and high-contrast LCD display for easy entry and reading of, e.g., tare weights, reference weights, limit values etc.
- Three displays for weight display (verifiable), reference weight, total pieces
- Precise counting: The manual reference weight optimisation gradually improves the average value of the piece weight
- Totalising of pieces when counting
- Printout with date and time
- Protective working cover over the display device included with the delivery
- Plastics technology
- Warehouse logistics
- Dispatch
- Counting applications
- Order picking and inventory
Weighing range (Max): 75 kg; 150 kg
Readability (g): 0,001 kg; 0,002 kg
Reproducibility: 0,001 kg; 0,002 kg
linearity: ± 0,006 kg; 0,01 kg
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-127
Material housing: stainless steel
Dimension housing (W×D×H): 285×255×90 mm
Dimension housing (Width): 285 mm
Dimension housing (Depth): 255 mm
Dimension housing (Height): 90 mm
Material weighing plate: stainless steel
Dimensions weighing surface (W×D): 252×200 mm
Dimension weighing surface (Width): 252 mm
Dimension weighing surface (Depth): 200 mm
Display type: LCD
Display digit height: 25 mm
Units: g; lb
Supplied power supply: Battery
Battery / accumulator type: Alkali(-Manganese)
Auto-off interval(s) in battery mode/rechargeable battery mode: 2 min
Battery: 4×1.5 V AA
Battery operating time: 48 h
Input voltage power supply / power [Max]: 230 V AC, 50 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,CH
Plug-in power supply / adapter for countries - option: EURO,UK,US,CH
Humity of environment [Min]: 25 %
Humity of environment [Max]: 95 %
Ambient temperature [Min] (°C): 5 °C
Ambient temperature [Max] (°C): 35 °C
Gross weight: 4,4 kg
Net weight: 3,8 kg
UN number (hazardous goods): 3496
UN number (hazardous goods): Drycell (UN number Alkaline: none, NiMH: 3496 - Packing instruction #1)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 420×350×175 mm
Dimensions packaging Width: 420 mm
Dimensions packaging Depth: 350 mm
Dimensions packaging Height: 175 mm
Total packaging weight: 465 g
Packaging component Paper: 100 g
Packaging component carton/cardboard: 285 g
Packaging component plastic: 285 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Pictograms Standard: External adjustment; Units switchable; Protection against dust and water splashes IP65; Prepared for battery operation; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Plug-in power supply 230V/50 Hz; Accredited calibration (DKD)
Accessories: FOB-A13S05; YKA-02; FOB-A13; YKA-29
