Counting System KERN CCS 150K0.1.

Counting system to count the smallest parts in large quantities, maximum number of parts which can be displayed is 999,999

• The highly accurate KERN CCS counting system can replace a whole range of individual balances, efficiently and at a reasonable price

Reference scale KERN CFS 6K0.1

• This professional counting scale, which can also be used as a stand-alone scale, meets the highest demands for accuracy, weighing capacity and volume of items, by being connected to a high-capacity weighing bridge
• Programmable using numerical key pad:
  - required reference quantity
  - known reference weight
• Three displays for weight display, reference weight, total pieces
• Memory (PLU) for items with additional text, reference weight and tare weight, e.g. of a container
• Fill-to-target function: Target count or target weight can be programmed. When the target weight is reached there is an audible and visual signal
• Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
• Protective working cover included with delivery

Quantity scale KERN KFP-V20 IP65

• The high-accuracy quantity counting takes place on the weighing platform. In this way even the smallest of parts can be counted in large volumes
• Weighing plate stainless steel, painted steel base
• Aluminium singlepoint load cell (1×3000 e), protection against dust and water splashes IP65

• Quality assurance
• Counting applications
• Assembly and parts logistics
• Packaging industry
• Order picking and inventory

Quantity scale - Weighing range: 150 kg
Quantity scale - readability : 0,005 kg
Reference scale - Weighing range: 6 kg
Reference scale - Readability: 100 mg
Reproducibility: 0,0002 kg
linearity: ±
Weighing system: Strain gauge
Article number for DAkkS calibration: 963-129
Material housing: plastic
Dimension completely mounted (W×D×H): 434×370×40 mm
Dimension completely mounted (Width): 434 mm
Dimension completely mounted (Depth): 370 mm
Dimension completely mounted (Height): 40 mm
Material weighing plate: plastic
Dimension weighing platform (W×D×H): 433×370×40 mm
Dimension weighing platform (Width): 433 mm
Dimension weighing platform (Depth): 370 mm
Dimension weighing platform (Height): 40 mm
Dimensions weighing surface (W×D): 430×370 mm
Dimension weighing surface (Width): 430 mm
Dimension weighing surface (Depth): 370 mm
Display type: LCD
Display digit height: 30 mm
Units: kg; lb
Supplied power supply: Battery
Battery / accumulator type: Alkali(-Manganese)
Auto-off interval(s) in battery mode/rechargeable battery mode: 15 sec
Battery: 4×1,5 V AAA
Battery operating time: 20 h
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 3,6 kg
Net weight: 3,2 kg
UN number (hazardous goods): Drycell (Alkalines, nickel-cadmium, zinc-carbon, Packing instruction #1, Not Restricted as per Special Provision A123)
Airworthy: yes, with dispatch instructions (in accordance with IATA classification)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 510×420×83 mm
Dimensions packaging Width: 510 mm
Dimensions packaging Depth: 420 mm
Dimensions packaging Height: 83 mm
Total packaging weight: 516 g
Packaging component Paper: 27 g
Packaging component carton/cardboard: 826 g
Packaging component plastic: 16 g
Packaging component Styrofoam: 46 g
Pictograms Standard: Units switchable; Prepared for battery operation; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Accredited calibration (DKD)
Accessories: 969-517
Technical Data Sheet (PDF)
