- With the TÜV certification mark, the scale meets the requirements of the standard EN 13155 (Non-fixed load lifting attachments/Breakage resistance) and EN 61010-1 (Electrical safety)
- Housingstainless steel, IP65-protected against dust and water splashes
- Ideal for rapid control in goods-in and goods-out
- Also essential in the private sector to determine the weight of fish, game, fruits, bicycle parts, suitcases etc.
- Hold function: For easy reading of the weighing result, the display can be "frozen" in different ways. Either automatically when the weighing value remains unchanged or manually by pressing the Hold key
- Peak load display (peak hold)
- Internal measuring frequency:5 Hz
- Snap link (stainless steel) with safety catch as standard
- Hook (stainless steel) as standard
- Food industry
- Commercial fishing
- Construction and building sites
- Warehouse logistics
- Agriculture and forestry
Weighing range (Max): 200 kg
Readability (g): 0,5 kg
Reproducibility: 0,5 kg
linearity: ± 1 kg
Weighing system: Tuning fork
Stabilization time: 3 s
Article number for conformity assessment: 965-216
Article number for DAkkS calibration: 963-127
Material housing: cast aluminium
Dimension housing (W×D×H): 220×333×93 mm
Dimension housing (Width): 220 mm
Dimension housing (Depth): 333 mm
Dimension housing (Height): 93 mm
Material weighing plate: stainless steel
Dimensions weighing surface (W×D): 200×200 mm
Dimension weighing surface (Width): 200 mm
Dimension weighing surface (Depth): 200 mm
Display type: Fluorescent
Display digit height: 14 mm
Units: kg; g; ct
Supplied power supply: Power supply unit
Input voltage power supply / power [Max]: 100-240V AC; 0,6 A; 50/60Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,AUS,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,AUS,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 standard,Digital I/O (optional, factory)
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): 10 °C
Ambient temperature [Max] (°C): 30 °C
Gross weight: 8 kg
Net weight: 6 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 330×440×215 mm
Dimensions packaging Width: 330 mm
Dimensions packaging Depth: 440 mm
Dimensions packaging Height: 215 mm
Total packaging weight: 1150 g
Packaging component Paper: 165 g
Packaging component carton/cardboard: 905 g
Packaging component plastic: 30 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 100 g
Pictograms Standard: Internal adjustment; Data interface RS-232; Piece counting function; Net-Total function; Percentage determination function; Units switchable; Measuring with tolerance range (checkweighing function); Plug-in power supply 230V/50 Hz; Weighing principle: Tuning fork; Package shipment 1 day
Pictograms Option: Suspended weighing; Universal plug-in power supply; Accredited calibration (DKD)
Pictograms Factory: Control output (optocoupler, digital I/O); Conformity assessment
Accessories: PES-A03; PES-A02; YKI-02; PES-A04S05; YKG-01; YKH-01; 474-926; MLB-A05; YPS-03; YPS-04; YPS-05; YKC-01; YKI-10; YKI-11; YKI-12; YKT-01; PES-A04
