High-Speed Industrial Camera Allied Vision HR 100GigE hr929C100GE-RF
Downloads:
PDF Instruction 1
The Allied Vision hr929C100GE-RF is a cutting-edge high-resolution industrial camera engineered for ultra-fast machine vision applications. Featuring the premium Sony IMX929 CMOS sensor with a 50.40 Megapixel resolution (8200 x 6152) and a high-efficiency Global Shutter, it captures crystal-clear color images of high-speed processes without motion artifacts or blur.
Equipped with an advanced 100GigE digital interface via QSFP28 and supporting the GigE Vision 3.0 standard, this camera transfers massive image data streams at up to 225 frames per second. An integrated 4032 MB image buffer ensures reliable burst data capture, while the versatile Canon RF lens mount provides broad flexibility for advanced optics setups.
Application Scenarios
- Ultra-high resolution aerial imaging and geospatial mapping
- Semiconductor wafer and flat panel display (FPD) automated optical inspection
- High-speed sports tracking and broadcast motion analysis
- Continuous web inspection in paper, foil, and textile production
- Advanced scientific research and particle image velocimetry
Specifications
| Parameter | Value |
| Model Code | hr929C100GE-RF (F004335) |
| Sensor Model | Sony IMX929 (CMOS, Color) |
| Shutter Type | Global Shutter |
| Resolution | 50.40 MP (8,200 x 6,152 pixels) |
| Pixel Size | 2.74 um x 2.74 um |
| Sensor Size | 22.47 x 16.86 mm (Type 1.8) |
| Max Frame Rate | 225 fps |
| Spectral Range | 400 nm to 1000 nm |
| Digital Interface | 100GigE (QSFP28 connector) |
| Vision Standard | GigE Vision 3.0 |
| On-Board RAM Buffer | 4032 MB |
| Non-Volatile Flash | 32768 MB |
| Exposure Time Range | 8 us to 60 s |
| Gain Range | 0.0 dB to 48.0 dB |
| Lens Mount | RF-Mount |
| GPIO / Interface Connector | 12-pin Hirose HR10A-10P-12S (RS422, 24V I/O) |
| Power Requirements | 24 to 25 VDC (33 W typical) |
| Dimensions / Weight | 109 x 69 x 69 mm / 570 g |
| Protection Class | IP30 |
| Operating Temperature | -10 °C to 60 °C |
Package Contents
- Allied Vision HR 100GigE hr929C100GE-RF camera body
- RF-Mount protective dust cap
- Quick start factory documentation
