Heavy-Duty Hydraulic Submersible Water Pump HWP4
Downloads:
PDF Instruction 1
The Hydraulic Submersible Pump HWP4 is a high-capacity industrial dewatering solution engineered to deliver exceptional performance under extreme site conditions. Boasting an impressive maximum discharge flow of up to 180 m³/h and a head elevation up to 20 meters, this robust unit handles heavy-duty groundwater lowering tasks efficiently. Its compact design and high output make it a highly cost-effective replacement for traditional, bulkier pumping systems when powered by standard hydraulic power packs or machinery.
Equipped with a specialized impeller design and a direct drive hydraulic motor, the pump is capable of handling solid particles with diameters up to 74 mm without clogging. The integrated direct-drive design ensures seamless continuous operation and protects internal seals and mechanical components even in dry-running scenarios. This feature guarantees maximum uptime, lower maintenance costs, and prolonged operational lifetime in demanding environments.
Applications
- Groundwater lowering and heavy-duty civil engineering dewatering
- Pumping slurry, mud, and water containing heavy suspended solids
- Emergency flood control and municipal disaster relief operations
- Utility trench pumping and industrial pit cleaning
- Agricultural drainage and reservoir transfer tasks
Specifications
| Item Number | 3030004 |
| Hydraulic Oil Flow | 30-40 LPM / 8-11 GPM |
| Maximum System Pressure | 172 bar / 2500 PSI |
| Maximum Flow Capacity | 180 m³/h / 790 GPM |
| Maximum Pumping Head | 20 m |
| Max Solid Particle Size | Ø 74 mm |
| Discharge Outlet Connection | 4 inch BSP female thread |
| Weight | 26.7 kg |
| Certification | CE approved |
Standard Package
- Hydraulic Submersible Pump HWP4 unit
- User manual and operation instructions
- (Note: Discharge hose and couplings sold separately)
