- Adjusting program CAL for quick setting of the balance accuracy using an external test weight at an additional price, see test weights
- Metal housing: robust and sturdy
- Dosage aid: High stability mode and other filter settings can be selected
- Weighing with tolerance range (checkweighing): a visual signal helps with portioning, dispensing or grading
- Summation of weight values
- Identification number: 4 digits, printed on calibration protocol freely programmable
- Automatic data output to the PC/printer each time the balance is steady
- Protective working cover included with delivery
- Laboratory applications
- Pharmaceutical applications
- quality control
- Time-based recording
Weighing range (Max): 4200 g
Readability (g): 0,01 g
Reproducibility: 0,01 g
linearity: ± 0,02 g
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-129
Material housing: plastic
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 500×400×127 mm
Dimension weighing platform (Width): 500 mm
Dimension weighing platform (Depth): 400 mm
Dimension weighing platform (Height): 127 mm
Dimensions weighing surface (W×D): 500×400 mm
Dimension weighing surface (Width): 500 mm
Dimension weighing surface (Depth): 400 mm
Display type: LCD
Display digit height: 52 mm
Units: kg; g; t
Supplied power supply: Power supply unit
Auto-off interval(s) in battery mode/rechargeable battery mode: off,5 min,15 min
Battery: no battery
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US
Plug-in power supply / adapter for countries - option: EURO,UK,US,CH
Plug-in power supply type: USB including power supply
Interfaces: RS-232 standard,USB,Ethernet (optional, factory),WiFi (optional, factory),Bluetooth (v4.0) (optional, factory)
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 15 kg
Net weight: 14 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 555×930×215 mm
Dimensions packaging Width: 555 mm
Dimensions packaging Depth: 930 mm
Dimensions packaging Height: 215 mm
Total packaging weight: 1,5 kg
Packaging component Paper: 100 g
Packaging component carton/cardboard: 750 g
Packaging component plastic: 750 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Load cell connection: 6-wire
Pictograms Standard: External adjustment; KERN IoT-ready; Data interface RS-232; Data Interface USB; Interface command set KERN Communication Protocol (KCP); Units switchable; Load Cell: Protection against dust and water splashes IP65; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: EasyTouch compatible; Accredited calibration (DKD)
Pictograms Factory: Data Interface Bluetooth; Data Interface WiFi; Network interface
Accessories: YRO-02; YKV-A02; 572-926; YKV-A01; YKA-31; YKV-A03
