- Adjusting program CAL for quick setting of the balance accuracy using an external test weight at an additional price, see test weights
- Metal housing: robust and sturdy
- Dosage aid: High stability mode and other filter settings can be selected
- Weighing with tolerance range (checkweighing): a visual signal helps with portioning, dispensing or grading
- Summation of weight values
- Identification number: 4 digits, printed on calibration protocol freely programmable
- Automatic data output to the PC/printer each time the balance is steady
- Protective working cover included with delivery
- Laboratory applications
- Pharmaceutical applications
- quality control
- Time-based recording
Weighing range (Max): 620 g
Readability (g): 0,001 g
Reproducibility: 0,001 g
linearity: ± 0,002 g
Supplied power supply: Power supply unit
Input voltage power supply / power [Max]: 100 V - 240 V AC 50/60 Hz 0,3 A
Plug-in power supply / adapter for countries - included with the delivery: EURO
Plug-in power supply / adapter for countries - option: EURO,UK
Plug-in power supply type: Power adapter
Gross weight: 10 kg
Net weight: 8 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 640×380×280 mm
Dimensions packaging Width: 640 mm
Dimensions packaging Depth: 380 mm
Dimensions packaging Height: 280 mm
Total packaging weight: 2 kg
Packaging component Paper: 2 g
Packaging component carton/cardboard: 1328 g
Packaging component plastic: 6 g
Packaging component Styrofoam: 664 g
Packaging component foam: 0 g
Optical system: Infinity
Tube type: Trinocular
Tube angle of inclination: 30°
Interpupillary distance [Min]: 50 mm
Interpupillary distance [Max]: 75 mm
Objectives magnifications: 5 x / 10 x / 20 x / 50 x
Nosepiece screw-in locations: 4
Ocular type: Eyepiece HWF 10x / Ø 20mm with anti-fungus, high eye point
Ocular magnifications: 10x
Ocular visual field: 20 mm
Illuminance: Reflected light
Illumination type incident light: LED
Illumination intensity incident light: 5 W
Illumination type transmitted light: None
Light distribution: 20:80
Pictograms Standard: 360° rotatable microscope head; Trinocular microscope; LED lighting; Polarisation unit; Infinity system; Length measurement; Plug-in power supply 230V/50 Hz; Package shipment 1 day
Accessories: OBB-A1353; OBB-A1354; OBB-A1355; OBB-A1325; ODC 832; ODC 825; OBB-A1514; OBB-A1515; OBB-A1523; OBB-A1530; ODC 241; ODC 841; OBB-A1623; OCS 901; OCS-A1101; OBB-A1655; OBB-A1672; OBB-A1673; OBB-A1388
