Quantity
|
Cost
|
||
|
|
|||
|
|
|||
- With SAUTER scale kits, individual weighing solutions can be put together, for example, individual balance manufacturing in industry, automotive manufacturing and agriculture. In this way, a wide range requirements in terms of dimensions, materials, combinations of peripheral devices etc. can be fulfilled. Especially suitable for the manufacture of platform scales, weigh hoppers, silo scales, flush-mounted floor scales and other weighing devices. Area of use: Measuring mass as well as compressive force in harsh environments
- Details for weighing cells (4 × SAUTER CT 1000-3P2):
- Accuracy in accordance with OIML R60 C3
- Protection against dust and water splashes IP67 (in accordance with EN 60529)
- Nickel-plated steel
- 4-wire connection
- Nominal sensitivity: 3 mV/V - Junctionbox SAUTER CJ P4PG:
- The robust aluminium diecast housing
- Protection against dust and water splashes IP65
- Mechanical engineering and plant construction
- Logistics and packaging
- Food industry
- Servicing and workshop
- Container and silo weighing
- Chemical industry
- Pharmaceutical applications
Weighing range (Max): 3000 kg
Accuracy classe: III
Supplied power supply: Power supply unit
Input voltage power supply / power [Max]: 100 - 240 V AC, 50/60 Hz, 1,0 A
Plug-in power supply / adapter for countries - included with the delivery: EURO
Plug-in power supply / adapter for countries - option: AUS,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: USB 3.0
Gross weight: 2,6 kg
Net weight: 2,6 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 270×250×130 mm
Dimensions packaging Width: 270 mm
Dimensions packaging Depth: 250 mm
Dimensions packaging Height: 130 mm
Total packaging weight: 164 g
Packaging component Paper: 0 g
Packaging component carton/cardboard: 159 g
Packaging component plastic: 5 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Camera resolution: 20 MP
Camera sensor type: Sony CMOS
Camera sensor size: 1"
Pictograms Standard: Data Interface USB; PC software; Package shipment 1 day
Accessories: OXM 902; ODC-A2404; ODC-A8108; MLB-A07; 822-903; MLB-A09; YKK-01
Technical Data Sheet (PDF)
