- Simple and convenient 2-key operation
- Tare function facilitates formulation work
- Particularly flat design
- Ready for use: Batteries included
- Hook for underfloor weighing standard
- Note: With the optional auxiliary set for density determination KERN YDB-04 also well suited for school and teaching operation, see accessories
As School Balance
- Teaching and training
- educational institutions
- Cosmetics industry
- Quality assurance
As Small Pet Scale
- veterinary practices
- Weighing small animals
- Breeding small animals
Weighing range (Max): 1000 g
Readability (g): 0,01 g
Reproducibility: 0,01 g
linearity: ± 0,05 g
Weighing system: Strain gauge
Stabilization time: 3 s
Article number for conformity assessment: 965-229
Article number for DAkkS calibration: 963-129
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 500×400×127 mm
Dimension weighing platform (Width): 500 mm
Dimension weighing platform (Depth): 400 mm
Dimension weighing platform (Height): 127 mm
Dimensions weighing surface (W×D): 500×400 mm
Dimension weighing surface (Width): 500 mm
Dimension weighing surface (Depth): 400 mm
Display type: LCD
Display digit height: 48 mm
Units: kg; g; ffa; PCS; %
Supplied power supply: Power supply unit
Battery / accumulator type: Li-Ion
Rechargeable battery optional: Rchrg. battery optional - intern
Rechargeable battery charging time: 8 h
Rechargeable battery operating time - backlight on: 20 h
Rechargeable battery operating time - backlight off: 48 h
Auto-off interval(s) in battery mode/rechargeable battery mode: 5 min,2 min,1 min,30 min,60 min,30 sec
Battery: no battery
Input voltage power supply / power [Max]: 110 V - 240 V AC
Plug-in power supply / adapter for countries - included with the delivery: EURO
Plug-in power supply type: Built-in power supply
Interfaces: RS-232 (optional, factory),Ethernet (optional, factory),WiFi (optional, factory),Alibi memory (optional, factory),analogue (0 - 10 V) (optional, factory),analogue (4 - 20 mA) (optional, factory),Bluetooth BLE (v4.0) (optional, factory),USB-Device (optional, factory)
Humity of environment [Min]: 0 %
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 14 kg
Net weight: 11 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 928×550×210 mm
Dimensions packaging Width: 928 mm
Dimensions packaging Depth: 550 mm
Dimensions packaging Height: 210 mm
Total packaging weight: 2750 g
Packaging component carton/cardboard: 1375 g
Packaging component Styrofoam: 1375 g
Load cell connection: 6-wire
Pictograms Standard: External adjustment; KERN IoT-ready; Interface command set KERN Communication Protocol (KCP); Piece counting function; Sum function; Percentage determination function; Measuring with tolerance range (checkweighing function); Hold function (average value); Load Cell: Protection against dust and water splashes IP65; Protection against dust and water splashes IP68; Integrated power supply unit 230 V/50 Hz; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: EasyTouch compatible; Accredited calibration (DKD)
Pictograms Factory: Alibi memory; Data interface RS-232; Data Interface USB; Data Interface Bluetooth; Analogue interface; Network interface; GLP/ISO Protocol; Value & time; Rechargeable battery; Conformity assessment
Accessories: BFS-A07; YKA-01; CFS-A03; YKR-01; YKA-02; YKN-01; YRO-02; KXS-A07; KXS-A07S05; YKG-01; YKH-01; KUM-05; KUM-06; KUM-01; KUM-03; KUM-04; KUM-08; IXC-A01; IXC-A02; YMM-06; YKC-01; YKT-01
