SVS-Vistek FXO fxo536CXGE 10GigE Color Camera
Downloads:
PDF Instruction 1
The SVS-Vistek FXO fxo536CXGE is a high-performance industrial camera equipped with the advanced Sony IMX536 CMOS sensor. Delivering a resolution of 8.10 megapixels at an impressive 149.8 frames per second, this camera is tailored for demanding machine vision applications requiring real-time color image processing.
Featuring an ultra-fast 10GigE digital interface (10GBase-T) with GigE Vision 2.0 and 3.0 compliance, the camera ensures high bandwidth data transfer, low CPU load via RDMA support, and precise multi-camera synchronization using IEEE 1588 PTP protocol. Built in a robust IP30 housing measuring 76 x 50 x 50 mm, it incorporates 896 MB RAM image buffer for reliable frame transmission.
Applications
- High-speed inline quality inspection in electronics manufacturing
- Automated optical inspection (AOI) for PCB assembly
- Traffic monitoring and intelligent transportation systems
- Pharmaceutical packaging and print verification
- Industrial robotics and real-time motion analysis
Specifications
| Sensor Model | Sony IMX536 CMOS Color |
| Resolution | 2848 x 2848 (8.10 MP) |
| Shutter Type | Global Shutter |
| Frame Rate | 149.8 fps |
| Pixel Size | 2.74 µm x 2.74 µm |
| Sensor Size | 7.8 x 7.8 mm (Type 2/3) |
| Interface | 10GigE (RJ-45) |
| Vision Standard | GigE Vision 2.0, 3.0, PTP, RDMA |
| On-board Memory | 896 MB RAM, 32 MB Flash |
| Dynamic Range / Exposure | 5 µs to 60 s, Gain 0 to 48 dB |
| I/O Ports | 12-pin Hirose, 2x 24V In, 4x Open Drain Out, RS232, Opto-In |
| Power Supply | 10 to 25 V DC (12W typical) |
| Lens Mount | C-Mount |
| Dimensions and Weight | 76 x 50 x 50 mm, 240 g |
| Operating Temperature | -10 °C to +60 °C (housing) |
| Filter Glass | IR-Cut 680 |
Package Contents
- SVS-Vistek FXO fxo536CXGE 10GigE Color Camera
- C-Mount protective cap
- Industrial dynamic safety documentation
