- Compact size, practical for small spaces
- Percentage determination: makes it possible to store a given weight value (100 %) and to determine deviations from this target value
- Protective working cover included with delivery
Weighing range (Max): 4000 g
Readability (g): 1 g
Reproducibility: 1 g
linearity: ± 2 g
Weighing system: Strain gauge
Stabilization time: 3 s
Article number for DAkkS calibration: 963-127
Material housing: ABS plastic
Dimension housing (W×D×H): 163×245×65 mm
Dimension housing (Width): 163 mm
Dimension housing (Depth): 245 mm
Dimension housing (Height): 65 mm
Dimension completely mounted (W×D×H): 163×245×123 mm
Dimension completely mounted (Width): 163 mm
Dimension completely mounted (Depth): 245 mm
Dimension completely mounted (Height): 123 mm
Material weighing plate: plastic
Dimension weighing surface (Ø): 82 mm
Display type: LCD
Display digit height: 25 mm
Units: kg; g; gn; dwt; ozt; lb; oz; ffa; PCS
Supplied power supply: Power supply & battery function (battery not included)
Battery / accumulator type: Li-Ion
Rechargeable battery optional: Rchrg. battery optional
Rechargeable battery charging time: 8 h
Rechargeable battery operating time - backlight on: 24 h
Rechargeable battery operating time - backlight off: 48 h
Auto-off interval(s) in battery mode/rechargeable battery mode: off,5 min,2 min,1 min,30 min,60 min,30 sec
Battery: 4×1.5 V AA
Battery operating time: 20 h
Input voltage power supply / power [Max]: 100 V - 240 V, 50 / 60 Hz
Plug-in power supply / adapter for countries - included with the delivery: EURO,UK,US,CH
Plug-in power supply / adapter for countries - option: EURO,UK,US,CH
Plug-in power supply type: Power adapter
Interfaces: RS-232 (optional),Ethernet (optional),Bluetooth BLE (v4.0) (optional),USB-Device (optional),KUP,WiFi (optional)
Humity of environment [Max]: 80 %
Ambient temperature [Min] (°C): -10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 1,8 kg
Net weight: 0,85 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 235×365×175 mm
Dimensions packaging Width: 235 mm
Dimensions packaging Depth: 365 mm
Dimensions packaging Height: 175 mm
Total packaging weight: 960 g
Packaging component carton/cardboard: 960 g
Pictograms Standard: External adjustment; KERN IoT-ready; Data interface KERN Universal Port (KUP); Interface command set KERN Communication Protocol (KCP); Piece counting function; Measuring with tolerance range (checkweighing function); Suspended weighing; Prepared for battery operation; Universal plug-in power supply; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: EasyTouch compatible; Data interface RS-232; Data Interface USB; Data Interface WiFi; Data Interface Bluetooth; Network interface; Rechargeable battery; Accredited calibration (DKD)
Accessories: CFS-A03; YKR-01; CFS-A04; 326-08; AFH 13; YKG-01; YKH-01; KUP-01; KUP-03; KUP-04; KUP-05; KUP-06; KUP-13; YBA-A12S05; YKT-01; YKA-27; YBA-A12
