- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
- Programmable using numerical key pad:
- required reference quantity
- known reference weight - Three displays for weight display (verifiable), reference weight, total pieces
- Fill-to-target function: Target count or target weight can be programmed. When the target weight is reached there is an audible and visual signal
- 10 memories for reference weights
- Counting results memory: adds up all individual piece counts, result is shown in total weight and total pieces
- Integrated ESD protection, which makes it ideal for weighing small plastic parts
- Energy management: Backlight turns off after 5 sec
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- Two balances in one: Changes from counting mode to weighing mode at the touch of a key
- Protective working cover included with delivery
- Warehouse logistics
- Packaging industry
- Retail
- Counting applications
- Order picking and inventory
Weighing range (Max): 30000 g
Readability (g): 10 g
Verification value [e]: 10 g
Accuracy classe: III
Minimum weight (min): 200 g
Reproducibility: 10 g
linearity: ± 20 g
Weighing system: Strain gauge
Stabilization time: 2 s
Article number for DAkkS calibration: 963-127
Material housing: stainless steel
Dimension housing (W×D×H): 150×170×40 mm
Dimension housing (Width): 150 mm
Dimension housing (Depth): 170 mm
Dimension housing (Height): 40 mm
Material weighing plate: stainless steel
Dimension weighing platform (W×D×H): 150×120×8 mm
Dimension weighing platform (Width): 150 mm
Dimension weighing platform (Depth): 120 mm
Dimension weighing platform (Height): 8 mm
Dimensions weighing surface (W×D): 120×150 mm
Dimension weighing surface (Width): 120 mm
Dimension weighing surface (Depth): 150 mm
Display type: LCD
Display digit height: 20 mm
Units: g; lb
Supplied power supply: Battery
Battery / accumulator type: Alkali(-Manganese)
Auto-off interval(s) in battery mode/rechargeable battery mode: 3 min,off,4 min,5 min,2 min
Battery: 9 V block
Battery operating time: 20 h
Battery operating time - backlight off: 20 h
Input voltage power supply / power [Max]: 230 V AC, 50 Hz
Plug-in power supply / adapter for countries - option: EURO,UK,CH
Plug-in power supply type: Power adapter
Humity of environment [Min]: 25 %
Humity of environment [Max]: 95 %
Ambient temperature [Min] (°C): 10 °C
Ambient temperature [Max] (°C): 40 °C
Gross weight: 0,90 kg
Net weight: 0,80 kg
UN number (hazardous goods): 3496
UN number (hazardous goods): Drycell (UN number Alkaline: none, NiMH: 3496 - Packing instruction #1)
Shipping method: Parcel service
Dimensions packaging (W×D×H): 255×195×75 mm
Dimensions packaging Width: 255 mm
Dimensions packaging Depth: 195 mm
Dimensions packaging Height: 75 mm
Total packaging weight: 118 g
Packaging component Paper: 100 g
Packaging component carton/cardboard: 59 g
Packaging component plastic: 59 g
Packaging component Styrofoam: 0 g
Packaging component glass: 0 g
Packaging component wood: 0 g
Packaging component metal: 0 g
Packaging component foam: 0 g
Pictograms Standard: External adjustment; Units switchable; Protection against dust and water splashes IP65; Prepared for battery operation; Weighing principle Strain gauges; Package shipment 1 day
Pictograms Option: Plug-in power supply 230V/50 Hz; Accredited calibration (DKD)
Accessories: FOB-A12S05; 346-76; YKA-46; FOB-A10; FOB-A12
