- stackable
Material housing: metal, lacquered
Dimension housing (W×D×H): 200×300×800 mm
Dimension housing (Width): 200 mm
Dimension housing (Depth): 300 mm
Dimension housing (Height): 800 mm
Dimension completely mounted (W×D×H): 200×300×800 mm
Dimension completely mounted (Width): 200 mm
Dimension completely mounted (Depth): 300 mm
Dimension completely mounted (Height): 800 mm
Gross weight: 14 kg
Net weight: 12 kg
UN number (hazardous goods): no dangerous goods
Airworthy: yes, without restrictions
Shipping method: Parcel service
Dimensions packaging (W×D×H): 200×300×800 mm
Dimensions packaging Width: 200 mm
Dimensions packaging Depth: 300 mm
Dimensions packaging Height: 800 mm
Total packaging weight: 2,7 kg
Measuring range force [Max] (N): 500 N
Overload protection (% of [Max]): 150%
Generated force [Max]: 500 N
Type of drive: manual crank handle
Travel distance per knob rotation (stroke per one turn): 3 mm
Directions of force: tension,compression
Pictograms Standard: Length measurement; Delivery_Express_1_day
Accessories: FS 2-20; FS 4-20; FS 2-50; FS 4-50; FS 2-100; FS 4-100; FS 2-200; FS 4-200; FS 2-500; FS 4-500
