Challenge

Rapid thermal annealing (RTA) requires extremely fast and precise heating of semiconductor wafers to temperatures exceeding 1000 °C within seconds. Achieving uniform temperature distribution across the wafer surface is critical, as even slight variations can lead to defects, stress, or inconsistent electrical properties.

However, accurate temperature measurement in RTA processes is highly challenging. Silicon exhibits varying emissivity depending on temperature, wavelength, and surface condition, making reliable infrared measurement complex. Additionally, interference from high-intensity heat sources such as quartz lamps, as well as silicon’s transparency at lower temperatures, further complicates signal detection. These factors make conventional temperature measurement methods insufficient for precise in-situ monitoring.

Solution

Infrared ratio (two-color) pyrometers with fiber-optic sensing heads provide a robust and reliable solution for high-temperature monitoring in rapid thermal annealing processes. By measuring radiation at two wavelengths and calculating their ratio, these systems compensate for emissivity variations and optical disturbances, ensuring accurate and stable temperature readings.

Fiber-optic designs allow the sensing head to be positioned close to the wafer inside confined or harsh environments, while sensitive electronics remain safely outside. This enables non-contact, contamination-free measurement while maintaining high durability under extreme thermal and chemical conditions.

Integrated into real-time monitoring and control systems, infrared pyrometers enable precise temperature tracking throughout the rapid heating and cooling cycles, ensuring optimal process control and repeatability.

Benefits

  • Ensures precise and uniform wafer heating, improving electrical performance and yield
  • Enables real-time detection and correction of temperature deviations
  • Eliminates contamination risks through non-contact measurement
  • Reduces thermal stress, minimizing wafer damage and breakage
  • Improves production efficiency with fast, reliable, and cost-effective monitoring

The Role of Rapid Thermal Annealing in Semiconductor Manufacturing

Thermal annealing is a critical process in semiconductor manufacturing used to activate dopants, repair crystal defects, and relieve internal stresses in silicon wafers. Traditional annealing methods relied on resistive-heated furnaces operating in inert environments, typically at temperatures between 900 °C and 1100 °C for extended periods.

Rapid thermal annealing represents a significant advancement in this field. Instead of prolonged heating cycles, RTA systems heat wafers to high temperatures—often above 1000 °C—within seconds, followed by controlled cooling to prevent thermal shock. This approach minimizes unwanted diffusion while maintaining precise control over material properties.

Various heating technologies are used in RTA systems, including quartz halogen lamps, induction heating, and resistive heating. Regardless of the method, maintaining accurate and uniform temperature is essential for achieving consistent results and high device performance.

Challenges of Measuring Silicon Temperature in RTA Processes

One of the main challenges in RTA is the complex thermal behavior of silicon. Its emissivity changes significantly with temperature, wavelength, and surface conditions, making single-wavelength measurement unreliable.

In lamp-based systems, additional complications arise from the spectral overlap between the heating source and the measurement signal. Quartz lamps emit strong radiation around 1 µm, which can interfere with infrared sensors and lead to inaccurate readings if the sensor detects the lamp instead of the wafer.

Furthermore, silicon behaves differently across temperature ranges. At lower temperatures, it is partially transparent to infrared radiation, while at higher temperatures it becomes opaque. This transition makes it difficult to select a single measurement wavelength suitable for the entire process.

To overcome these challenges, advanced infrared measurement techniques are required, often combining multiple sensors or using scanning systems to evaluate temperature uniformity across the wafer.

Accurate Temperature Monitoring with Infrared Ratio Pyrometry

Ratio pyrometers provide a significant advantage in RTA applications by reducing sensitivity to emissivity variations and optical disturbances. By comparing radiation at two wavelengths, they deliver more reliable temperature readings even in dynamic and high-radiation environments.

Fiber-optic ratio pyrometers are particularly well suited for semiconductor processes. Their compact sensing heads can be installed in confined spaces near the wafer, while the electronics are protected from heat, vibration, and chemical exposure. This design ensures long-term stability and measurement accuracy.

Advanced ratio algorithms further enhance performance by adapting to changes in emissivity, allowing consistent and precise temperature monitoring even under rapidly changing process conditions.

Optimizing RTA Processes with Reliable Infrared Monitoring

Accurate temperature measurement is essential for maintaining process stability and achieving high yield in semiconductor manufacturing. Infrared pyrometers integrated into control systems provide real-time feedback, enabling precise adjustment of heating power and ensuring uniform temperature distribution across the wafer.

In applications requiring detailed thermal profiling, multiple pyrometers or infrared line-scanning systems can be used to monitor temperature uniformity across the entire wafer surface. This helps identify hotspots or gradients that could affect device performance.

Modern infrared monitoring solutions also offer advanced software capabilities, including real-time visualization, data logging, and remote configuration. These tools provide full process transparency and enable continuous optimization.

Durable and Cost-Effective Temperature Monitoring Solutions

Infrared temperature measurement systems for RTA must combine precision, durability, and cost efficiency. Fiber-optic ratio pyrometers meet these requirements by delivering reliable performance in extreme environments without interfering with the process.

Their non-contact operation eliminates contamination risks, while robust construction ensures long service life even under high temperatures and aggressive conditions. In addition, fast response times allow immediate process adjustments, improving throughput and reducing downtime.

Economically, these systems provide high accuracy at a competitive cost, enabling faster implementation and shorter development cycles. Combined with ongoing technical support and system integration capabilities, they represent a comprehensive solution for modern semiconductor manufacturing.

Rapid thermal annealing is a critical process that demands precise and reliable temperature control under extreme conditions. Infrared ratio pyrometry provides the accuracy, stability, and flexibility required to meet these challenges.

By enabling non-contact, real-time temperature monitoring, these systems improve wafer quality, reduce defects, and enhance overall production efficiency. As semiconductor technologies continue to evolve, advanced infrared temperature measurement remains an essential tool for achieving consistent, high-performance results in RTA processes.
